Panasonic KX-UT670 Corded SIP Telephone

The Panasonic KX-UT670 smart desk phone is a Linux Based, programmable SIP desk phone with an extensive feature set. The UT670 boasts high audio quality with extensive codec support, including the G.722 wideband codec. A full duplex speaker phone is included, along with built-in support for 3 way conference calls and compatibility with Plantronics Electronic Hook Switch systems for superb hands-free performance.

The UT670 features two Gigabit Ethernet ports with support for Power over Ethernet (PoE), giving the opportunity to reduce cabling to the desktop.

The device features a 7 inch colour touch screen with a simple to use graphical user interface, which gives easy access to a variety of included applications such as a web browser, calendar, e-mail, contacts manager, network camera control, music player and more – with the possibility to create and install custom applications to meet specific requirements.

Applications for the KX-UT670 can be developed using an open-source SDK for Android development, along with the KX-UT670 APIs. Programs are developed using the Java programming language. Code editing and compiling can be done in Eclipse, though other editors and compilers may be used.

Key Features

High Definition HD Voice

The KX-UT series of SIP terminals offers ‘best in class’ audio quality, meaning fewer repeated conversations and misheard calls. Offering Wideband High Definition voice as standard across the range, the KX-UT series offer various codecs, including G.722, G.711 and G729a. Coupled with Enhanced Echo Cancellation and an Expanded Acoustic Chamber, the KX-UT series of SIP terminals offers a superior audio experience to users over handset, speakerphone and optional headsets. The entire range features wideband compliant, hearing aid compatible handsets, and built-in, high quality speaker and microphone.

LCD Displays
Large, clear LCD displays with intuitive User Interface offer fast access to phonebooks and features.

Electronic Hook Switch (EHS)
A built in Electronic Hook Switch (Plantronics compliant) port allows the KX-UT670, KX-UT248, KX-UT133 and KX-UT136 SIP Terminals to have access to the Plantronics range of wireless headsets. This offers a range of portability and comfort as frequent users are able to move around freely, without being tied down by handsets.

ECO Friendly
Low power consumption, combined with an advanced ECO standby mode means lower energy costs. Consumption can be as low as 1 watt in ECO mode*.

Plug and Play Configuration
Extensive provisioning options, including automatic configuration via a provisioning server, means a smaller administration overhead, saving time and money. The range is certified compatible with Digium Asterisk and Broadsoft Broadworks, ensuring excellent compatibility with leading soft switch suppliers.

Features

• 7" Touch Screen Display
• 720p HD Video
• Desk Mountable (2 Positions)
• Optional Wall Mount
• 2 Ethernet Ports
• PoE
• Optional Bluetooth
• 15 Handset/Headset Volume Levels
• 32 Ringtones
• 7 Ringer Volume Levels
• 2.5mm Headset Port
• Compatible With 3.5mm Plantronics Electronic Hook Switch
• Audio Codec - G.711, G.722, G.729a
• Softkeys On Screen
• 24 Programmable Keys
• All Keys On Screen
• Phonebook (Dependant On Memory)
• 100 Incoming & 100 Outgoing Call Log
• 3 Party Conferencing
• Music On Hold (Dependant On PBX/SIP Server)
• Up to 6 SIP Accounts
• SIP Compatibility - RFC 3261 Standard SIP Server, Asterisk, Broadsoft, Panasonic SIP PBX
• IPv4
• DHCP Client - Yes
• DNS - Yes
• HTTP - Yes
• HTTPS - Yes
• SNTP Client - Yes
• VLAN (802.1q) - Yes
• QoS (Diffserv) - Yes
• 802.1x - No
