Mitel 5634 Wi-Fi IP Phone

The Mitel 5634 Wi-Fi Phone is a feature rich SIP enabled VoWiFi Phone that is ideally suited for businesses that require both wireless voice and data communications.

True VoWiFi Performance in Three Models

The new Mitel 5634 VoWiFi Phone combines the reliability, ease-of-management and performance of VoWiFi with enterprise-grade ruggedness, ergonomics and stylish design. The Wireless product line include the following new VoWiFi Handset and upgrade licenses:

• Mitel 5634 Handset
• Mitel 5634 Messenger (License Upgrade)
• Mitel 5634 Alarm (License Upgrade)

The Mitel 5634 VoWiFi delivers exceptional network and roaming performance.

Easy to Use. Easy to Manage. Easy to Secure

Rugged durability, centralized management and OTA updates mean a low Total Cost of Ownership and easy administration. Various authentication and encryption methods provide robust enterprise grade security.

Built to Work and Work and Work

A 920mAh battery provides up to 100 hours of stand-by and ten hours of speech time. The sturdy body is dust and water resistant to IP44 standard and can be safely cleaned with common disinfectants.

Bluetooth and Locating

All models are Bluetooth enabled, allowing wireless headsets to be used for handsfree operation. The Alarm model is compatible with IR and LF. Messenger and Alarm models also support Bluetooth Low Energy location systems, WLAN access points, Cisco MSE and AiRISTA Flow RTLS location systems.

Enterprise Grade VoWiFi Performance and Seamless Roaming

Supports four network systems, with auto and manual selection. Seamless roaming is optimized with 802.11r, 802.11K, and opportunistic key and pairwise master (PMKSA) caching.

Easy to Use

Bluetooth-enabled headset allows handsfree operation. Large, easy-to-read screen and a light weight (only 135g / 4.8oz) help make the Mitel 5634 comfortable to use for even the longest shifts.

Smooth Device Management

Enterprise-grade centralized management lets administrators configure all settings remotely. Validated interoperability with major PBX and Wi-Fi vendors.

Protects Users and Colleagues

The Mitel 5634 Alarm model features push-button alarms. Multiple device location methods are available for both the Alarm and Messenger models.

Mobility with Confidence

The Mitel 5634 makes it easy to optimize workflow productivity. Features such as outstanding voice quality, a multilingual user interface, messaging capabilities and extensive phone book options help keep users connected to colleagues, events and mission-critical information.

Features

• Dimensions 137 × 52 × 21 mm - (L x W x D)
• Weight - 135g (Battery and Clip Included)
• 240 × 320 Pixel LCD Colour Screen with White Backlighting
• 3 Programmable Soft Keys
• 9 Programmable Hot Keys
• Push Button Alarm
• Up to 1000 Entries with Company Phone Book
• Up to 250 Entries in Local Phone Book
• 14 Ring Signals, Flashing LED and Vibrator
• Supports WiFi 802.11 a/b/g/n/ac Standards
• Hearing Aid Compatible (HAC)
• Bluetooth 5.0 for Headset
• Standard 3.5mm Headset Connector
• Illuminated Display for Incoming Calls and Charging
• 4 Way Navigation Key
• Handsfree with Duplex Loudspeaker

Technical Specifications:

Display

• 31 x 41mm (2.0 Inches) TFT Colour Display - 240 x 320 Pixel LCD with White LED Backlight

Battery & Charging

• Battery Type - Li-Polymer 3.7V 920mAh
• Talk Time - 10 Hours
• Standby Time - 100 Hours
• Charge Time - Approximately 4 Hours

Connectors

• Multi-Purpose Connector - With USB for Fast Software Download, Configuration, and Battery Charging
• Headset Connector - 3.5mm Jack

Menu and Message Languages

• Arabic, Chinese (simplified), Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Norwegian, Polish, Portuguese (Brazilian), Russian, Slovak, Spanish, Swedish, and Turkish

Phonebook

• Central Phonebook - Unlimited Entries
• Company Phonebook - 1000 Entries
• Local Phonebook - 250 Entries

Telephony Indication

• Illuminated Display
• Vibrator
• 14 Ring Signals
• Aggressive Ring Signal
• 5 Beep Signals
• 3 User Defined Custom Sounds

Location and Alarm

• Location Types - IR, LF (Alarm)
• Messenger and Alarm - BLE, Associated WLAN Access Point (AP), Cisco MSE, AiRISTA Flow RTLS
• Supported Alarm Types - Push Button Alarm, Acoustic Location Signal (ALS), Automatic Emergency Call After Alarm

Bluetooth

• Supported Version - 5.0
• Supported Profiles - Headset and Handsfree

WLAN

• Quality of Service (QoS) - WMM, TSPEC-based CAC
• Supported Networks - 802.11 a/b/g/n/ac (MCS0-7)

Security

• Security Standard - 802.11i, 802.11w
• Encryption Methods - AES-CCMP, TKIP
• Authentication Methods - Open, WPA/WPA2-PSK, PEAP-MSCHAPv2, EAP-TLS

Roaming Enhancement

• 802.11r, 802.11k
• OpportunisticKey Caching
• PMKSA Caching

Call List Capacity

• 25 Calls (Received, Dialed and Missed) with Time Stamp

Voice Codecs

• Opus Wideband, G.711 A-law (EU), G.711 u-law (US), G.722, G.729, G.729A, G.729B, and G.729AB

Compatible Mitel Platforms

• MiVoice Business, MiVoice MX-ONE and MiVoice 5000
