The Fanvil PA2 KIT is an accessory kit for use with the Fanvil SIP Intercom / Paging Gateway PA2. The accessory package includes Speaker Module, Microphone Module and Button Module. Users can quickly build high quality Audio/Video intercom equipment with the PA2 KIT, eliminating the components selection, and eliminating testing as this has already been done.
High Reliability
Waterproof and Dustproof Designed Stainless Steel Button with LED Indicator for Better Operation.
Fanvil PA2 KIT Highlights
High Reliability Components, Plug & Play
High Sensitivity Pick-Up, Waterproof, Dustproof Designed Microphone Module, Suitable for Harsh Environment Applications
5W / 8Ω Speaker Module, Satisfied the Noisy Environment to the Demand of the High Loudness of the Intercom Equipment
Waterproof and Dustproof Designed Stainless Steel Button with LED Indicator for Better Operation
Fanvil PA2 KIT Package Contents
Speaker Module x 1
Button Module x 1
Microphone Module x 1
Fanvil PA2 KIT Features and Functions:
Speaker Module Functions
Speaker with Self Adhesive Layer
Module with Dustproof, Waterproof Protective Film
5W / 8Ω Waterproof Loudspeaker
Speaker Module Features
The Diameter of the Horn is 57mm and the Height is 13.7mm - Includes 150cm Shielding Wire
5W / 8Ω Waterproof Loudspeaker
Button Module Functions
Stainless Steel Button with Backlight
IP67/IK10 Protection Level
Mechanical Lifetime of the Button is 200,000 Times
LED Lamp Lifetime is 400,000 Hours
Button Module Features
Button Diameter is 16mm and the Height is 23.8mm
The Button is Self Restorable Stainless Steel with 150cm Shielding Wire
Microphone Module Functions
Microphone with Self Adhesive Layer
Module with Dustproof, Waterproof Protective Film
Microphone Sensitivity: -38DB±2
Microphone Module Features
Standard Working Voltage - 3V, Maximum Voltage is 10V
Output Impedance - ≤2.2KΩ
Diameter of the Microphone is 9.7mm, Height is 4.7mm - Includes 150cm Shielding Wire
All information is provided for reference only. If you are unsure about any of the features listed, please check the manufacturer's official information.
